3 series 12V18650 lithium battery protection board 11.1V 12.6V defense over the peak of 10A overcurrent protection

Notice:

This protective board cannot be used for iron aggregate batteries, flashlight drilling battery packs, electric fish battery packs, electric bicycle battery packs, 2 again in series 24V, 775 (4A) motor, 1W fish eye LED light, for it for for for it for for for it for for it for forPlease pay attention to the customers purchased above!Essence

The described power range is applicable to the following products:

Vacuum cleaner massage battery pack, LED light spare power, 12V electronic products, solar street light battery packs, monitoring spare power supply, and other products.

Description explanation:

3 string (for 3 18650 batteries or polymer lithium batteries in series)

10.8V (rated voltage of polymer battery)

11.1V (rated voltage of 18650 or 3.7V lithium batteries)

12.6V (after the lithium battery is full of voltage)

Refining 10A (referring to the maximum discharge current)

Lithium battery protection board

Comb with it: over -charging, over -current, overcurrent, short -circuit protection

Essentials for 18650 lithium battery group!IntersectionIntersection

Overview:
The main IC uses the original "Seiko" imported components.It has protection functions such as overcharge, over -streaming, overcurrent, short -circuit, etc., for various shapes and shapes and shapes of 3.7V lithium batteries.Adopt high-quality MOSFET, such as Japanese Seiko-Protecting IC, Vishay, AOS, IR, etc., FR-4 low-temperature coefficient plate materials, well-designed and comprehensive testing.Small size, suitable for many occasions that require high integration and low cost, can meet various performance requirements, ensure the absolutely safe and reliable battery pack.

Attributes of the lithium battery protection board:

Model: HX-3S-01 over charge voltage range: 4.25-4.35V ± 0.05V

Size: 50*16*1.0mm Excessive voltage range: 2.3-3.0V ± 0.05V

Maximum working current: 5-8A working temperature: -40 ---+50 ℃

Maximum current current: 9-10A Storage Conditions: -40- +80 ℃

Static current: less than 6UA Able life: greater than 30,000 hours

Internal resistance: less than 60MΩ short circuit protection: protected, delayed self -recovery.

The size and device description of the protective board;

The size of this protective board is 50*16*1.0mm; the component is Seiko S-8254AA protection chip and genuine FDS 4435A*4;

Note: The nickel pieces and auxiliary materials described below. The price of the baby in this link is not included. The shipment is a single sheet. If you need to process the shipment, please contact the customer service to communicate.

Three strings and three combination methods upload later!
